15-Day Trial Version
Developer: Ahmed Zaitoon
Full version available at:
AZ Dev Store
Overview
AZ Dimension Tool is a powerful Tekla Structures extension that automates the creation of dimension lines in drawings. It significantly reduces manual dimensioning time while improving drawing consistency and accuracy.
By automating repetitive dimensioning tasks, it helps detailers and engineers produce professional drawings faster and more efficiently.
Key Features
Automated Dimension Lines
- Automatically creates dimension lines in Tekla drawings.
- Eliminates repetitive manual dimensioning tasks.
- Speeds up drawing production workflows.
Drawing Consistency
- Ensures standardized dimensions across all drawings.
- Reduces human errors in dimension placement.
- Produces clean and professional shop drawings.
Reduces Manual Effort
- Completes dimensioning tasks in seconds instead of hours.
- Increases detailing productivity.
- Helps shorten project delivery times.
